3 Axis Dispensing Robot with 600*600mm Working Range, ±0.02mm Repeat Accuracy, and 500mm/sec Max Speed for Precise Glue Application

Name: 3 Axis Dispensing Robot with 600*600mm Working Range, ±0.02mm Repeat Accuracy, and 500mm/sec Max Speed for Precise Glue Application
Brand: Zhongshan GDS Automation Equipment Co., Ltd.
SKU: HTD-600
Availability: InStock

Brand Name:	GDS
Model Number:	HTD-600
MOQ:	1 PIECE
Price:	CONTACT US
Delivery Time:	10 days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Name:

Glue Dispenser Robot

Function:

Dispensing Silicone

Application:

Kitchen Appliances

Warranty:

1 Year

After-sales Service:

On-line Or On-site

EXW Report:

Test Video Available

Packaging Details:

plywood case

Supply Ability:

30PCS/mon

Highlight:

600*600mm Working Range 3 Axis Dispensing Robot

±0.02mm Repeat Accuracy Glue Dispenser Robot

500mm/sec Max Speed Automated Glue Dispenser

Product Description

3-Axis Glue Dispensing Robot for Kitchen Appliances Manufacturing

Our advanced 3-Axis Glue Dispensing Robot delivers precision adhesive application capabilities specifically designed for kitchen appliances manufacturing automation. This industrial automation solution ensures consistent, high-quality bonding, sealing, and coating while reducing material waste and operational costs.

Key Advantages

Ultra-precise application with ±0.1mm repeatability for complex glue paths
Adaptive flexibility for various adhesives including silicones, epoxies, and UV-cured materials
Smart programming with user-friendly interface and CAD file integration
Industrial-grade construction with IP54-rated protection for harsh factory environments
Safety interlocks and collision detection for operator protection

Performance Benefits

30-50% faster cycle times compared to manual dispensing
Up to 20% adhesive waste reduction through optimized flow control
Elimination of human error for uniform adhesive distribution
Modular design for seamless integration with existing production systems

Applications in Kitchen Appliances

Sealant application for oven doors and dishwasher tubs
Gasket bonding in refrigerator compartments
Component assembly (handles, control panels, hinges)
Protective coating for electrical connectors

Technical Specifications

Model	HTD-600
MCU	3 axis movement controller
Programming	Teaching programming
Drive Mode	Precise Stepping Motor + Synchronous Belt + Linear Guide-way
Working Range (XYZ)	600600100mm
Max Moving Speed	MAX 500mm/sec
Repeat Accuracy	±0.02mm
Dimension (LWH)	7006501200mm
Working Power	AC220V/50～60Hz/150W
Working Air Pressure	0.4 ~ 0.6Mpa (no condensation)
Working Temperature and Humidity	Temperature: 0 ~ 40℃ Humidity: 20 ~ 90%

Compatible Adhesives

300ml package silicone or 2600ml package silicone

Machine Features

Industrial PLC controller with optimized settings for different glue types
Floor-stand design with wide working range (600*600mm)
Stable glue flow control without leakage or drawing
Enhanced water-proof and bonding performance
Small hand programming controller for easy operation
Accelerated gluing process capabilities
Compatible with various brand silicones in 300ml or 2600ml packages
